TP Toys active fun TP814 - Stage 12: Safety Toggle Attachment; Eliminating Potential Traps

15
TP Triple Round Wood Multiplay
Stage
12
Plastic Toggle
PM8387
x8
4 x 16mm
Woodscrew
x16
FA4527
x8
SLIDE END
IMPORTANT
ASSEMBLY TIP
TP Branding Badge
to face SLIDE END
of Platform
ASSEMBLY TIP
IMPORTANT
ASSEMBLY TIP
TOGGLES MUST BE
ATTACHED AS SHOWN.
THESE ARE TO ELIMINATE
POTENTIAL TRAPS
ie: CLOTHING WITH
STRAPS/TOGGLES.
TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 15 25/09/2017 10:41
