TP Triple Round Wood Multiplay
Stage
26
70mm Coachscrew x4
FA8439
45°
45°
45°
45°
Stake
PR5069
x4
x4
Ensure the stakes are
positioned into the
setting Post-Mix concrete.
Warning: Never
set the legs of the
playset in concrete.
Dig holes:
300mm x
300mm x
300mm deep.
Mark leg/hole position.
Not
Supplied.
Fill holes with Post-Mix concrete.Fix stakes to legs.
Drill 5mm
Pilot holes
1 2 3
5 64
x4
TP814
300mm
300mm
300mm
