25
TP Triple Round Wood Multiplay
Stage
25
Spacer
Bush (Bracket)
PM1989
x4
1
2
FA2826 Bolt/locknut Set
x2
M6 x 40mm
IMPORTANT
ASSEMBLY TIP
CHECK ALL BOLTS ARE
FULLY TIGHTENED.
35mm
40mm
ASSEMBLY TIP
Step
ladders
required.
TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 25 25/09/2017 10:42
