24
TP Triple Round Wood Multiplay
40mm Coach Screw
Drill 5mm
Pilot holes
Drill 5mm
Pilot holes
ASSEMBLY TIP IMPORTANT ASSEMBLY TIP
Drill 5mm
Pilot holes
NOW Fully tighten bolts.
Stage
24
40mm
Coach screw
FA8380
x4
Drill 5mm
Pilot holes
Gap between
Brackets may vary
Gap between
Brackets may vary
NOW
Fully tighten
bolts.
NOW
Fully tighten
bolts.
ASSEMBLY TIP
Step
ladders
required.
TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 24 25/09/2017 10:42
