TP Triple Round Wood Multiplay
Stage
23
Glide Ride
Bracket
PR5070
x2
M8
Nylon Insert Nut
FA5174
x2
M8 x 25mm
Bolt
FA8381
x2
Use Socket tool provided.
ASSEMBLY TIP
Drill 5mm
Pilot holes
ASSEMBLY TIP
Level
Level
ASSEMBLY TIP
Locate bolts only.
Do not fully tighten bolts just yet.
ASSEMBLY TIP
Step
ladders
required.
Position brackets using
pre-drilled hole on topbar
for guidance.
ASSEMBLY TIP
