22
TP Triple Round Wood Multiplay
Stage
22
Glider Downtube Top x2
MT0523
MT0523 MT0523
35mm
40mm
FA2829 Male/female Bolt Set
x2
M8 x 21mm
Spring
washer
IMPORTANT
ASSEMBLY TIP
CHECK ALL BOLTS ARE
FULLY TIGHTENED.
TP814 Roundwood Triple Multiplay NEW In0814-D 25.09.17.indd 22 25/09/2017 10:42
