Blue M - - DC 146 Series Industrial Ovens, Models DC, DCW, DCI, DCC
Page 24
Do not connect oven directly to a compressed gas cylinder or any other high pressure gas source.
Use only commercially prepared and bottled gases.
Do not exceed 70 PSIG gas inlet pressure.
Important! Refer to the Inert Gas Control System section for information on setting the flow rates
for your chamber.
INERT GAS SUPPLY CONNECTION
Gas Supply
Connection
Note: Gas Control
Housing Is Removed
To Next Page
