BLUE M
Blue M - - DC 146 Series Industrial Ovens, Models DC, DCW, DCI, DCC
Page 35
THERMOCOUPLE LOCATION – MODELS DC & DCI
MODEL DCC256 BLOWER DISCHARGE
THERMOCOUPLE LOCATION – MODEL DCC
Differential Air
Pressure
Sense Tubes
Model DCC256
Note: Thermocouples are
placed along the left wall
in the Model DCC only,
due to the Clean Room
Insert that is installed
inside the oven liner.
Models DC & DCI
Model DCC
Blower Discharge
Thermocouples
Thermocouples
Rear Wall
