TPS BLUE M ESP400 - Page 13

BLUE M
Model ESP400 Industrial Oven
Page 13
Left and right views of the machinery base are shown below. The unit is shown laying on its side.
Note: Your equipment configuration may be slightly different from what is shown.
MACHINERY BASE- ESP400 - Left
MACHINERY BASE - ESP400 - Right
Power Supply
Junction Box
Heater
Terminals
TC Wires
Circ.
Blower
Motor
Power
Supply
Cables
