ME500-X
Trackunit ME500-X, Technical Manual v.1.1, January
2016 Page 10
Installing the unit
Practical installation advice
• It is very important to be careful when installing the unit, as incorrect
installation will reduce the quality of the GPS position reports (Ex. could be a
jump in position or showing speed while parking) or in the worst case
scenario will prevent the unit performing any position reporting at all.
•
The unit must be mounted either horizontally or vertically (sideways) using either
screws or strips. The unit must not be installed with the interface/supply cable
hanging down, as this definitely will reduce the GPS sensitivity.
Optimize the placement of the unit to increase the aerial view (through windows
etc.) as much as possible. For hiding the unit, make sure it is only mounted beneath
plastic parts or similar parts (wood), but not beneath metal parts.
•
To reduce hum and noise in the FM radio it is recommended to place the unit at a
minimum distance of 20 inches (50 cm) from the radio or the loudspeakers.
Connections
The connections depend on the type of vehicles / machines etc. in which the GSM/GPS
unit is to be installed.
Different variants of the ME500-X device will have only a subset of the connections shown
in the table below. Please contact your nearest sales office, distributor or “Reseller” for
further information about the availability of other variants in your area.
(color code)
Red Supply voltage +12V / +24V
White Digital input 1
Brown Digital input 2 (Ignition)
Grey Digital input 3
Yellow Digital output 1
Green 1-Wire input
Pink Digital input 4
Black RS232 RX (Optional)
Violet RS232 TX (Optional)
Grey/Pink CAN HI (Optional)
Red/Blue CAN LO (Optional)
Blue Common ground
The unit must NOT be installed
inside closed metal compartments. Incorrect installation will
also reduce the standby time of the battery inside the unit
