Trackunit TU600B, Technical Manual v1.0, March 2022 Page 23
For mounting the Trackunit TU600B in harsh environment, not covered by the compliance
statements or areas where pressure cleaning is required the Trackunit HW shield PN
7402.9551 is required for protective mounting. Please order at Trackunit Aps.
Recommended fuse holders and fuses up to 48V supply voltages (Can be ordered at
Trackunit APS):
a. Supply voltage 12V/24V (Max 30A)
i. ATO blade fuses (Max 32V/1A) used with Littelfuse FHAC0002SXJ fuse
holder (Standard).
ii. ATP blade fuse (Max 32V/1A – ATO style) used with TaiTek FH-006WR-
12R-12-U fuse holder (Standard).
b. Supply voltage 12V – 48V (Max 30A)
i. FKS blade fuse (Max 80V/3A – ATO style) used with Littelfuse FH2 fuse
holder. (Recommended)
Left: 32V/1A fuse kit, Right: 80V/3A fuse kit
