Installing Viper Casters
POSITIONING THE U-SHAPED FIREPOT COVER
AND ANGLED DRIP PAN:
Become familiar with each of the components and how they fit inside your
barbecue.
STEP 4- HANGING THE GREASE BUCKET
Locate the grease drain tube (16) found at the bottom right hand side of the
main barbecue body. Hang the grease bucket (22) on the hook on the drain tube
(16).
Drip Pan
Support Bar
Angled drip pan
V channel
grease catch
Grease
drain tube
Firepot cover
and shield
Firepot
Auger tube
Angled Drip Pan
Short End of
Angled Drip Pan
With one person lifting up the barbecue body,
install the casters as indicated in the diagram.
Caster Pin
Rece
tacle
