www.TrailFX.com
Page 3 of 7
5
5. Set the tonneau onto the mounting rails, the buckles should be to the front.
6 & 7. Assemble the four retainer clamps, slide each of them into the track on the underside of the tonneau,
slide into position, but do not tighten at this time.
6 7
Bulkhead
Front Flap
Cover
Warning - Be sure Front ap is over the bulkhead
To Next Page
