2 TEE3C49A-SF-1B
Pressure Drop for BAYHTR14/34 Series Electric Heater Accessories
BAYHTR 1405 1408 1410
3410
1415
3415
1419 1425 AIRFLOW
RANGE
(CFM)
HEATER SIZE
(KW @ 240V)
4.80 7.68 9.60 15.36 19.20 24.96
AIR PRESSURE
DROP
(Inches W.G.)
0.14 0.17 0.17 0.20 0.23 0.26 1800 or
more
0.11 0.13 0.13 0.16 0.19 0.21 1000-1800
0.03 0.04 0.04 0.05 0.06 0.07 up to 1000
NOTES: 1. See product data or air handler nameplate for approved
combinations of air handlers and heaters.
2. Heater model number may have additional suffix digits.
Airflow Performance
2/4TEE3C49A1: with Wet coil, No Heaters, Filter
Outdoor
Airflow Settings
Airflow
EXTERNAL STATIC PRESSURE (in.w.g.)
Unit Size
Name CFM/ton
Power 0.1 0.3 0.5 0.7 0.9
Low 290
CFM
847 876 880 875 876
Watts
94 139 182 223 267
Med-Lo 350
CFM
1029 1045 1053 1051 1042
3
Watts
133 181 229 277 325
tons Med-Hi 400
CFM
1177 1191 1198 1196 1187
Watts
179 231 282 337 389
High 450
CFM
1326 1334 1335 1337 1326
Watts
235 292 347 402 464
Low 290
CFM
1013 1012 1007 993 966
Watts
144 188 232 275 315
Med-Lo 350
CFM
1204 1213 1214 1218 1206
3.5
Watts
190 239 292 349 392
tons Med-Hi 400
CFM
1375 1381 1382 1386 1373
Watts
257 314 370 430 488
High 450
CFM
1541 1546 1545 1544 1545
Watts
340 405 468 534 595
Low 290
CFM
1211 1220 1227 1225 1212
Watts
195 249 304 357 408
Med-Lo 350
CFM
1374 1382 1383 1388 1377
4
Watts
257 317 374 434 496
tons Med-Hi 400
CFM
1563 1571 1573 1574 1570
Watts
355 421 486 553 610
High 450
CFM
1746 1759 1766 1754 1734
Watts
478 552 626 695 738
Low 290
CFM
1415 1421 1420 1418 1422
Watts
282 342 400 463 520
Med-Lo 350
CFM
1707 1716 1717 1714 1727
5
Watts
446 519 588 658 731
tons Med-Hi 400
CFM
1953 1938 1878 1791 1707
Watts
638 710 734 722 747
High 450
CFM
2048 1962 1876 1788 1703
Watts
736 731 728 725 720
NOTES:
Airflow Demand is OD size (tons) * Speed (cfm/ton)
COMM SYS mode will auto-detect OD size, with default speed 400cfm/ton & 1.5 minute off-delay
At continuous fan setting: Airflow values are approximately 50% of listed values.
