88-A4AC3001-1J-EN 7
Section 5. Refrigerant Line Considerations
5.1 Refrigerant Line and Service Valve Connection Sizes
Table 5.1
Note: For other line lengths, Refer to Refrigerant Piping Application Guide, SS-APG006-EN or Refrigerant Piping
Software Program, 32-3312-xx (latest revision).
RATED
LINE SIZES
Line Sizes Service Valve Connection Sizes Max Line & Lift Lengths
Vapor
Line
Liquid
Line
Vapor Line
Connection
Liquid Line
Connection
TOTAL Max
Line Length (ft.)
Max Lift (ft.)
A4AC3018D
3/4 3/8 3/4 3/8
150 50
A4AC3023D
3/4 3/8 3/4 3/8
150 50
A4AC3024D
3/4 3/8 3/4 3/8
150 50
A4AC3030D
3/4 3/8 3/4 3/8
150 50
A4AC3035D
3/4 3/8 3/4 3/8
150 50
A4AC3036D
3/4 3/8 3/4 3/8
150 50
A4AC3042D
7/8 3/8 7/8 3/8
150 50
A4AC3048D
7/8 3/8 7/8 3/8
150 50
A4AC3060D
7/8 3/8 7/8 3/8
150 50
A4AC3018A
3/4 3/8 3/4 3/8
150 50
A4AC3023A
3/4 3/8 3/4 3/8
150 50
A4AC3024A
3/4 3/8 3/4 3/8
150 50
A4AC3029A
3/4 3/8 3/4 3/8
150 50
A4AC3030A
3/4 3/8 3/4 3/8
150 50
A4AC3036A
3/4 3/8 3/4 3/8
150 50
A4AC3042A
7/8 3/8 7/8 3/8
150 50
A4AC3043A
7/8 3/8 7/8 3/8
150 50
A4AC3048B
7/8 3/8 7/8 3/8
150 50
A4AC3060A
7/8 3/8 7/8 3/8
150 50
