26
18-GF16D1-1A-EN
Figure 18. A4AH4E30 — Front view
Snap
Tab
Feature
Remove 2 screws
and water diverter
bracket
Top Cap
Figure 19. A4AH4E30 — Front view
Snap
Tab
Feature
Replace 2 screws
and water diverter
bracket
Top Cap
Figure 20. A4AH4E30 — Rear view
Snap
Tab
Feature
Remove 2 screws
and water diverter
bracket
Figure 21. A4AH4E30 — Rear view
Snap
Tab
Feature
Replace 2 screws
and water diverter
bracket
CCooiill CCoonnvveerrssiioonn IInnssttrruuccttiioonnss
