Trane BAYEVBC15BK1A - Technical Data Tables

Page 12
INSTALLER'S GUIDE
Minimum Heating Airflow Settings
Section 7. Tables
MODEL NO.
BAYEVAC05BK1AA
BAYEVAC05LG1AA
BAYEVAC08BK1AA
BAYEVAC08LG1AA
BAYEVAC10BK1AA
BAYEVAC10LG1AA BAYEVAC10LG3AA BAYEVCB15LG3AA BAYEVBC15BK1AA BAYEVBC20BK1AA BAYEVCC25BK1AA
TAM7A0A24H21SB 638/713 638/900 675 1
/900 600/713 -- -- -- --
TAM7A0B30H21SB 723/808 723/1020 765/1020 680/808 765/1063 850/1105 -- --
TAM7A0C36H31SB 876/979 876/1236 927/1236 824/979 927/1288 1030/1339 1236/1442 --
TAM7A0C42H31SB 978/1093 978/1380 1035/1380 920/1093 1035/1438 1150/1495 1380/1610 --
TAM7A0C48H41SB 1063/1188 1063/1500 1125/1500 1000/1188 1125/1563 1250/1625 1500/1750 1625/1813
TAM7B0C60H51SA
TAM7A0C60H51SB 1063/1188 1063/1500 1125/1500 1000/1188 1125/1563 1250/1625 1500/1750 1625 1
/1813
WITHOUT HEAT PUMP / WITH HP
SEE AIR HANDLER NAMEPLATE FOR APPROVED COMBINATIONS
1
Heater not qualified for 208V when installed in horizontal left position without Heat Pump
MINIMUM HEATER AIRFLOW CFM - HEATER MATRIX
MODEL NO.
BAYEVAC05BK1AA
BAYEVAC05LG1AA
BAYEVAC08BK1AA
BAYEVAC08LG1AA
BAYEVAC10BK1AA
BAYEVAC10LG1AA BAYEVAC10LG3AA BAYEVCB15LG3AA BAYEVBC15BK1AA BAYEVBC20BK1AA BAYEVCC25BK1AA
TAM8A0A24V21CB 638/713 638/900 675 1
/900 600/713 -- -- -- --
TAM8A0B30V21CB 723/808 723/1020 765/1020 680/808 765/1063 850/1105 -- --
TAM8A0C36V31CB 876/979 876/1236 927/1236 824/979 927/1288 1030/1339 1236/1442 --
TAM8A0C42V31CB 978/1093 978/1380 1035/1380 920/1093 1035/1438 1150/1495 1380/1610 --
TAM8A0C48V41CB 1063/1188 1063/1500 1125/1500 1000/1188 1125/1563 1250/1625 1500/1750 1625/1813
TAM8A0C60V51CB
TAM8B0C60V51CA 1063/1188 1063/1500 1125/1500 1000/1188 1125/1563 1250/1625 1500/1750 1625 1
/1813
WITHOUT HEAT PUMP / WITH HP
SEE AIR HANDLER NAMEPLATE FOR APPROVED COMBINATIONS
1
Heater not qualified for 208V when installed in horizontal left position without Heat Pump
MINIMUM HEATER AIRFLOW CFM - HEATER MATRIX
MODEL NO.
BAYEVAC05BK1A
A
BAYEVAC05LG1AA
BAYEVAC08BK1A
A
BAYEVAC08LG1AA
BAYEVAC10BK1A
A
BAYEVAC10LG1AA BAYEVAC10LG3AA BAYEVCB15LG3AA BAYEVBC15BK1AA BAYEVBC20BK1AA BAYEVCC25BK1AA
TAMGA0A24H21SA 638/713 638/900 675 1
/900 600/713 -- -- -- --
TAMGA0C36H31SA 876/979 876/1236 927/1236 824/979 927/1288 1030/1339 1236/1442 --
TAMGA0C48H41SA 1063/1188 1063/1500 1125/1500 1000/1188 1125/1563 1250/1625 1500/1750 1625/1813
TAMGA0C60H51SA 1063/1188 1063/1500 1125/1500 1000/1188 1125/1563 1250/1625 1500/1750 1625 1
/1813
MINIMUM HEATER AIRFLOW CFM - HEATER MATRIX
SEE AIR HANDLER NAMEPLATE FOR APPROVED COMBINATIONS
1
Heater not qualified for 208V when installed in horizontal left position without Heat Pump
