CVGF-SVU02B-E4
29
Unit Control
Panel (UCP)
Reference
Top Level Mode Sub Level Mode BAS Code
SYSTEM RESET
NA
Stopped Local Stop 00
Stopped Panic Stop 00
Stopped Diagnostic Shutdown – Manual Reset 00
Run Inhibit Tracer Inhibit 100
Run Inhibit External Source Inhibit 100
Run Inhibit Diagnostic Shutdown – Auto Reset 100
Auto Waiting For Evaporator Water Flow 58
Auto Waiting For A Need To Cool 58
Auto Waiting For A Need To Heat 58
Auto Power Up Delay Inhibit: MIN:SEC 58
Waiting To Start Waiting For Condenser Water Flow 70
Waiting To Start Establishing Oil Pressure 70
Waiting To Start Pre-Lubrication Time: MIN:SEC 70
Waiting To Start Motor Temperature Inhibit: 70
Motor Temperature / Inhibit Temperature
Waiting To Start Restart Time Inhibit: MIN:SEC 70
Waiting To Start Low Oil Temperature Inhibit: 70
Oil Temperature / Inhibit Temperature
Waiting To Start Waiting For Starter To Start: MIN:SEC 70
Starting Compressor There is no sub mode displayed 72
Running There is no sub mode displayed 74
Running Surge 74
Running Base Loaded 74
Running Current Control Soft Loading 74
Running Capacity Control Soft Loading 74
Running – Limit Current Limit 75
Running – Limit Phase Unbalance Limit 75
Running – Limit Condenser Pressure Limit 75
Running – Limit Evaporator Temperature Limit 75
Running – Limit Minimum Capacity Limit 75
Running – Limit Maximum Capacity Limit 75
Preparing To Shutdown Closing IGV IGV Position % 7E
Shutting Down Post-Lubrication Time: MIN:SEC 7E
Shutting Down Evaporator Pump Off Delay: MIN:SEC 7E
Shutting Down Condenser Pump Off Delay: MIN:SEC 7E
Boot & Application software part number, self-test, and
configuration validity screens will be present.
