Trane CVGF-SVU02B-E4 - Page 35

CVGF-SVU02B-E4
35
Unit Control
Panel (UCP)
Compressor Report Items Units
Compressor Starts: ###
Compressor Running Time: Hour and minute
Oil Differential Pressure Switch Open or Closed
Oil Tank Temperature °C or °F
Vanes Position Percent open
Vanes Position Steps Steps
Motor Report Items Units
Percent RLA L1 L2 L3 Percent RLA
Amps L1 L2 L3 Amps
Volts AB, BC, CA Vac
Power Consumption, If installed xxx kW
Load Power Factor, If installed xx
Winding Temperature A °C or °F
Winding Temperature B °C or °F
Winding Temperature C °C or °F
ASHRAE Chiller Log Units
1. Current Time / Date HH:MM AM / PM MMM DD YYYY
2. Chiller Mode Stopped / Running
3. Amps L1 L2 L3 Amps
4. Volts AB BC CA Volts
5. Active Chiller Water Set Point F/ C
6. Active Current Limit Set Point %
7. Refrigerant Type 134a
8. Compressor Starts 0
9. Compressor Running Time 0:00
10. Oil Tank Temperature F/ C
11. Evaporator Entering Water Temperature F/ C
12. Evaporator Leaving Water Temperature F/ C
13. Evaporator Saturated Refrigerant Temperature F/ C
14. Evaporator Saturated Refrigerant Pressure PSIG / kPa
15. Evaporator Approach Temperature F/ C
16. Evaporator Water Flow Switch Status Flow / No Flow
17. Condenser Entering Water Temperature F/ C
18. Condenser Leaving Water Temperature F/ C
19. Condenser Saturated Refrigerant Temperature F/ C
20. Condenser Refrigerant Pressure PSIG / kPa
21. Condenser Approach Temperature F/ C
22. Condenser Water Flow Switch Status Flow / No Flow
