CVGF-SVU02B-E4
46
Base Loading
Control Algorithm
Figure 16. Base loading with external mA input and with external voltage input
Base Loading with External mA Input
%RLA
100
90
80
70
60
50
40
30
20
46 8101214161820
mA
—— %RLA
Base Loading using External Voltage Input
%RLA
100
90
80
70
60
50
40
30
20
46 8101214161820
Volts
—— %RLA
