Trane CVGF-SVU02B-E4 - Page 6

CVGF-SVU02B-E4
6
Figure 2. Component location for typical CVGF unit (back view)
Motor
Unit nameplate
Relief valves
Oil cooler
Economizer
Condenser
Two-Stage Compressor
Unit-Mounted Starter (Optional)
Relief Valves
Unit Nameplate
Control Panel CH530
Oil Pump
Evaporator
General
Information
Figure 1. General CVGF unit component
