General Data
50 and 60 Hz SI Units and (English Units)
High Effi ciency Shells - 0.75 inch (19 mm) Internally Enhanced Cu Tube:
Condenser:
Nominal Shell 500 500 500 700 700 700 1000 1000 1000 1000
Bundle Size Small Medium Large Small Medium Large Small Medium Large Extra Large
Number of Passes 2 2 2 2 22222 2
Min Flow L/s (gpm) 31 (487) 34 (542) 37 (586) 42 (668) 47 (744) 52 (816) 59 (938) 67 (1056) 74 (1176) 77 (1213)
Max Flow L/s (gpm) 113 (1786) 125 (1987) 136 (2148) 155 (2450) 172 (2727) 189 (2993) 217 (3441) 244 (3874) 272 (4311) 280 (4447)
Evaporator:
Nominal Shell 500 500 500 700 700 700 1000 1000 1000 1000
Bundle Size Small Medium Large Small Medium Large Small Medium Large Extra Large
Number of Passes 2 2 2 2 22222 2
Min Flow L/s (gpm) 26 (407) 29 (458) 32 (511) 36 (566) 40 (628) 44 (698) 52 (822) 58 (921) 64 (1021) 72 (1136)
Max Flow L/s (gpm) 94 (1493) 106 (1680) 118 (1873) 131 (2077) 145 (2304) 161 (2559) 190 (3013) 213 (3377) 236 (3745) 263 (4165)
Evaporator:
Nominal Shell 500 500 500 700 700 700 1000 1000 1000 1000
Bundle Size Small Medium Large Small Medium Large Small Medium Large Extra Large
Number of Passes 3 3 3 3 33333 3
Min Flow L/s (gpm) 17 (271) 19 (305) 21 (340) 24 (378) 26 (419) 29 (465) 35 (548) 39 (614) 43 (681) 48 (757)
Max Flow L/s (gpm) 63 (995) 71 (1120) 79 (1248) 87 (1385) 97 (1536) 108 (1706) 127 (2009) 142 (2251) 158 (2497) 175 (2777)
Standard Effi ciency Shells - 1.00 inch (25.4 mm) Int. Enhanced Cu Tube:
Condenser:
Nominal Shell 500 500 500 700 700 700 1000 1000 1000 1000
Bundle Size Small Medium Large Small Medium Large Small Medium Large Extra Large
Number of Passes 2 2 2 2 2 2222 2
Min Flow L/s (gpm) 31 (499) 35 (557) 38 (606) 43 (682) 48 (764) 53 (838) 58 (925) 64 (1020) 75 (1172) 83 (1307)
Max Flow L/s (gpm) 115 (1831) 129 (2041) 140 (2221) 158 (2501) 177 (2801) 194 (3071) 214 (3391) 236 (3741) 276 (4372) 302 (4792)
Evaporator:
Nominal Shell 500 500 500 700 700 700 1000 1000 1000 1000
Bundle Size Small Medium Large Small Medium Large Small Medium Large Extra Large
Number of Passes 2 2 2 2 2 2222 2
Min Flow L/s (gpm) 28 (447) 31 (496) 35 (550) 39 (625) 45 (706) 49 (784) 49 (781) 236 (3741) 63 (1003) 70 (1115)
Max Flow L/s (gpm) 103 (1638) 115 (1818) 127 (2018) 145 (2293) 181 (2874) 181 (2874) 181 (2864) 207 (3287) 232 (3678) 258 (4090)
Evaporator:
Nominal Shell 500 500 500 700 700 700 1000 1000 1000 1000
Bundle Size Small Medium Large Small Medium Large Small Medium Large Extra Large
Number of Passes 3 3 3 3 3 3333 3
Min Flow L/s (gpm) 19 (298) 21 (330) 23 (367) 26 (417) 30 (471) 33 (523) 33 ((521) 38 (598) 42 (669) 47 (744)
Max Flow L/s (gpm) 69 (1092) 76 (1212) 85 (1346) 96 (1529) 109 (1726) 121 (1916) 120 (1909) 138 (2191) 15 (2452) 172 (2726)
Table GD-3 –Evaporator and Condenser Flow Rates (Minimum and Maximum, liters per second, gallons per minute)
