N = 80 KVAR
P = 90 KVAR
R = 100 KVAR
T = 120 KVAR
U = 125 KVAR
V = 150 KVAR
S = Special
A = (15th Digit) Ground Fault Protection
0 = None
A = Ground Fault Protection
S = Special
0 = (16th digit) Special Options
0 = None
S = Special Options ( See Sales Order)
E = (17th digit) Literature Language
E = English
F = French
G = German
P = Spanish
T = Italian
S = Special
1 = (18th digit) Oil Pump Starter Circuit
1 = 1 HP Oil Pump Motor
2 = 1.5 HP Oil Pump
Service Model Numbers - Wye-delta Motor Starter
An example of a typical chiller starter model number is:
CVSN0035FAA01EA0E1
Model Number Digit Identification - Model number digits are selected and assigned
in accordance with the following definitions using the model number example shown
above.
C = (1st digit)
V = 2nd digit)
S = (3rd digit)
N = (4th digit) Development Sequence
N = Cutler-Hammer electrical-mechanical starter for gear drive centrifugal chillers with
AdaptiView controls
0035 = (5th, 6th, 7th, and 8th digit) Starter Size
F = (9th digit) Unit Voltage
D = 380V-60Hz-3Ph
F = 460V-60Hz-3Ph
H = 575V-60Hz-3Ph
R = 380V-50Hz-3Ph
T = 400V-50Hz-3Ph
U = 415V-50Hz-3Ph
S = Special
A = (10th digit) Design Sequence
A = Original Design
A = (11th digit) Starter Type
A = Star-Delta - Unit Mounted
C = Star-Delta - Remote Mounted
CVGF-SVX03B-EN
16
General Information
