Trane CVGF1000 - Page 23

Table 3. General data: 650 ton units (continued)
Nominal T
onnage 650
1.0 0.75
Two Three Two Three
Wa
ter Volume - 150 pound Waterboxes
163.2 158.2 154.1 149.1
(618) (599) (583) (564)
185.1 185.1 188.5 188.5
(701) (701) (714) (714)
Evaporator 2-pass W
eight
Supply - pound 304 304 304 304
(kg) (138) (138) (138) (138)
Return - pound 337 337337 337
(kg) (153)(153) (153) (153)
Evaporator 3-pass W
eight
Supply - pound 314 314 314 314
(kg) (142) (142) (142) (142)
Return - pound 332 332332 332
(kg) (151)(151) (151) (151)
Condenser 2-pass W
eight
Supply - pound 304 304 304 304
(kg) (138) (138) (138) (138)
Return - pound 341 341341 341
(kg) (155)(155) (155) (155)
300 pound W
aterboxes
163.2 158.2 154.1 149.1
(618) (599) (583) (564)
185.1 185.1 189.4 189.4
(701) (701) (717) (717)
Evaporator 2-pass W
eight
Supply - pound 427 427 427 427
(kg) (194) (194) (194) (194)
Return - pound 446 446446 446
(kg) (202)(202) (202) (202)
Evaporator 3-pass W
eight
Supply - pound 448 448 448 448
(kg) (203) (203) (203) (203)
Return - pound 448 448448 448
(kg) (203)(203) (203) (203)
Condenser 2-pass W
eight
Supply - pound 421 421 421 421
(kg) (191) (191) (191) (191)
Return - pound 436 436436 436
(kg) (198)(198) (198) (198)
Evaporator W
ater
Storage gallon (l)
Condenser W
ater
Storage gallon (l
)
Evaporator W
ater
Storage (gallon (l))
Condenser W
ater
Storage gallon (l)
Evaporator W
ater Pass
T
ube Outside
Diameter (inch)
CVGF-SVX03B-EN
23
General Information
