Trane CVGF1000 - Page 29

Table 5. General data: 800 ton units (continued)
Nominal T
onnage 800
1.0 0.75
Two Three Two Three
Wa
ter Volume - 150 pound Waterboxes
190.4 185.4 177.4 172.4
(721)(702) (672) (653)
213.5 213.5 218.0 218.0
(808)(808) (828) (828)
Evaporator 2-pass W
eight
Supply - pound 303.57 303.57 303.57 303.57
(kg) (137.7)(137.7) (137.7) (137.7)
Return - pound 337.16337.16 337.16 337.16
(kg) (152.9) (152.9) (152.9) (152.9)
Evaporator 3-pass W
eight
Supply - pound 313.56 313.56 313.56 313.56
(kg) (142.2)(142.2) (142.2) (142.2)
Return - pound 331.72331.72 331.72 331.72
(kg) (150.5) (150.5) (150.5) (150.5)
Condenser 2-pass W
eight
Supply - pound 303.69 303.69 303.69 303.69
(kg) (137.8)(137.8) (137.8) (137.8)
Return - pound 340.67 340.67 340.67 340.67
(kg) (154.5) (154.5) (154.5) (154.5)
300 pound W
aterboxes
190.4 185.4 177.4 172.4
(721)(702) (672) (653)
214.5 214.5 219.0 219.0
(812)(812) (829) (829)
Evaporator 2-pass W
eight
Supply - pound 426.69 426.69 426.69 426.69
(kg) (193.5)(193.5) (193.5) (193.5)
Return - pound 446.20446.20 446.20 446.20
(kg) (202.4) (202.4) (202.4) (202.4)
Evaporator 3-pass W
eight
Supply - pound447.81 447.81 447.81 447.81
(kg) (203.1)(203.1) (203.1) (203.1)
Return - pound 447.98447.98 447.98 447.98
(kg) (203.2) (203.2) (203.2) (203.2)
Condenser 2-pass W
eight
Supply - pound 421.43 421.43 421.43 421.43
(kg) (191.2) (191.2) (191.2) (191.2)
Return - pound 436.11 436.11 436.11 436.11
(kg) (197.8) (197.8) (197.8) (197.8)
Evaporator W
ater Pass
Evaporator W
ater Storage
gallon (l)
Condenser W
ater Storage
gallon (l)
Evaporator W
ater Storage
gallon (l)
Condenser W
ater Storage
gallon (l)
T
ube Outside Diameter
(inch
)
CVGF-SVX03B-EN
29
General Information
