Unit Nameplates
The CVGF unit nameplate (Figure 2 shows the nameplate location) is applied to the
exterior surface of the control panel. The starter nameplate is located inside the starter
panel.
The unit nameplate provides the following information:
unit electrical requirements - Lists correct operating charges of HFC-134a and lubrica-
tion oil - Lists unit test pressures and maximum working pressures The starter name-
plate provides the following information:
Unit Inspection
When the unit is delivered, verify that it is the correct unit and that it is properly
equipped.
Inspect all exterior components for visible damage. Report any apparent damage or
material shortage to the carrier and make a "unit damage" notation on the carrier’s de-
livery receipt. Specify the extent and type of damage found and notify the appropriate
Trane Sales Office.
Do not proceed with installation of a damaged unit without sales office approval.
Inspection Checklist
To protect against loss due to damage incurred in transit, complete the pre-commis-
sioning checklist, which can be obtained from your Trane representative.
-
vious damage to the unit
it is stored. Concealed damage must be reported within 10 days after receipt.
damaged material from the receiving location. Take photos of the damage, if possible.
The owner must provide reasonable evidence that the damage did not occur after de-
livery.
however, until damage is inspected by the damage is inspected by the transportation
Loose Parts Inventory
The loose parts items ship in the motor junction box for units without a unit-mount-
ed starter, or in the starter panel for units equipped with a unit-mounted starter. This
includes the isolation pads, extra oil filter, and any optional optional factory-shipped
items.
CVGF-SVX03B-EN
8
General Information
