Base Loading with External mA Input
%RLA
100
90
80
70
60
50
40
30
20
4 6 8 10 12 14 16 18 20
mA
—— %RLA
Base Loading using External Voltage Input
%RLA
100
90
80
70
60
50
40
30
20
4 6 8 10 12 14 16 18 20
Volts
—— %RLA
Figure 32. Base loading with external mA input and with external voltage input
CVGF-SVX03B-EN
89
Base Loading Control Algorithm
