Trane IntelliPak SAHL Series User Manual

108 RT-SVX36G-EN
Unit Start Up
Table 35. Service test guide for component operation — Part I of II
Component
Being Tested
COMPONENT CONFIGURATION
Supply
Fan
Return
Fan
Exhaust
Fan
Condenser
Fans
Heat Stages Compressor Stage
1231234
COMPRESSOR
20 - 30 Ton
A OFF OFF OFF A-Off/B-On OFF OFF OFF K10-On K11-Off N/A N/A B OFF OFF OFF A-On/B-Off OFF OFF OFF K10-Off K11-On N/A N/A
40 - 60 Ton
1A OFF OFF OFF 1A-Off/1B-On OFF OFF OFF K11-On K3-Off K12-Off K4-Off
2A-Off/2B-Off
1B OFF OFF OFF 1A-On/1B-Off OFF OFF OFF K11-Off K3-Off K12-On K4-Off
2A-Off/2B-Off
2A OFF OFF OFF 1A-Off/1B-Off OFF OFF OFF K11-Off K3-On K12-Off K4-Off
2A-Off/2B-On
2B OFF OFF OFF 1A-Off/1B-Off OFF OFF OFF K11-Off K3-Off K12-Off K4-On
2A-On/2B-Off
70 - 105 Ton
1A OFF OFF OFF 1A-Off/1B-On OFF OFF OFF K11-On K3-Off K12-Off K4-Off
2A-Off/2B-Off
1B OFF OFF OFF 1A-On/1B-Off OFF OFF OFF K11-Off K3-Off K12-On K4-Off
2A-Off/2B-Off
2A OFF OFF OFF 1A-Off/1B-Off OFF OFF OFF K11-Off K3-On K12-Off K4-Off
2A-Off/2B-On
2B OFF OFF OFF 1A-Off/1B-Off OFF OFF OFF K11-Off K3-Off K12-Off K4-On
2A-On/2B-Off
115 - 130 Ton
1A & 1B OFF OFF OFF 1A-Off/1B-On OFF OFF OFF K11-Off K3-Off K12-On K4-Off
2A-Off/2B-Off
2A & 2B OFF OFF OFF 1A-Off/1B-Off OFF OFF OFF K11-Off K3-Off K12-Off K4-On
2A-Off/2B-On
CONDENSER FANS
20 Ton - Air Cooled
A-2B1 OFF OFF OFF A-On/B-Off OFF OFF OFF OFF OFF OFF OFF
B-2B2 OFF OFF OFF A-Off/B-On OFF OFF OFF OFF OFF OFF OFF
25 - 30 Ton - Air Cooled
A-2B1 OFF OFF OFF A-On/B-Off OFF OFF OFF OFF OFF OFF OFF
B-2B2/2B3 OFF OFF OFF A-Off/B-On OFF OFF OFF OFF OFF OFF OFF
40 Ton - Air Cooled
1A-2B1 OFF OFF OFF 1A-On/1B-Off OFF OFF OFF OFF OFF OFF OFF
2A-Off/2B-Off
1B-2B2 OFF OFF OFF 1A-Off/1B-On OFF OFF OFF OFF OFF OFF OFF
2A-Off/2B-Off
2A-2B4 OFF OFF OFF 1A-Of/1B-Off OFF OFF OFF OFF OFF OFF OFF
2A-On/2B-Off
2B-2B5 OFF OFF OFF 1A-Off/1B-Off OFF OFF OFF OFF OFF OFF OFF
2A-Off/2B-On
50 Ton - Air Cooled
1A-2B1 OFF OFF OFF 1A-On/1B-Off OFF OFF OFF OFF OFF OFF OFF
2A-Off/2B-Off
1B-2B2/2B3 OFF OFF OFF 1A-Off/1B-On OFF OFF OFF OFF OFF OFF OFF
2A-Off/2B-Off
2A-2B4 OFF OFF OFF 1A-Off/1B-Off OFF OFF OFF OFF OFF OFF OFF
2A-On/2B-Off
2B-2B5/2B6 OFF OFF OFF 1A-Off/1B-Off OFF OFF OFF OFF OFF OFF OFF
2A-Off/2B-On
