RT-SVX36G-EN 125
Unit Start Up
75/89
12000 0.28 0.38 .10 .08 0.06 .10 .13 .06 .11 .05 .05 .01 .44 .37 .02 .07 0.03
16000 0.44 0.58 .18 .14 0.11 .17 .21 .11 .19 .07 .07 .02 .63 .58 .05 .10 0.06
20000 0.63 0.82 .27 .21 0.17 .24 .31 .16 .27 .10 .10 .03 .84 .82 .10 .16 0.09
22000 0.73 0.94 .33 .25 0.2 .29 .37 .19 .33 .12 .12 .04 .95 .95 .13 .20 0.11
24000 0.84 1.07 .40 .30 0.24 .33 .42 .22 .39 .14 .14 .04 1.06 1.08 .16 .23 0.13
26000 0.95 1.2 .47 .32 0.28 .39 .49 .27 .45 .16 .16 .05 1.17 1.23 .23 .26 0.15
28000 1.07 1.33 .54 .33 0.32 .44 .55 .32 .50 .17 .17 .06 1.22 1.29 .30 .30 0.17
31000 1.27 1.54 .60 .40 0.4 .49 .61 .39 .55 .21 .21 .07 - - .37 .36 0.21
33000 1.4 1.68 .65 .46 0.45 .52 .67 .44 .60 .24 .24 .08 - - .42 .40 0.24
Notes:
1. Static pressure drops of accessory components must be added to external static pressure to enter fan selection tables.
2. Gas heat section maximum temperature rise of 60 F.
3. Throwaway filter option limited to 300 ft/min face velocity.
4. Bag filter option limited to 740 ft/min face velocity.
5. Horizontal roof curbs assume 0.50" static pressure drop or double the standard roof curb pressure drop, whichever is greater.
6. No additional pressure loss for model SXHL.
Table 38. Component static pressure drops (in. W.G.)
Nom
(AC/
EC)
Cfm
Std
Evaporator Coil
Heating System
Filters
Std
Roof
Economizer
With or
Without
Exhaust
Reheat
Option
Pressure
Drop
Throwaway
Perm
Wire
Bag and
Prefilter
Cartridge
and
PrefilterDry
Wet
SFHL SEHL SLHL SSHL
Std. High Low High All kW Low High Low High
Table 39. Component static pressure drops, 90-130 ton (in. W.G.)
Nom
Cfm
Std
Evaporator Coil High Cap Evap
Heating System
Filters
Std
Roof
Econ.
w/ or
w/out
Exhaust
Throwaway
Perm
Wire
Bag
and
Prefilter
Cartridge
and
PrefilterDry
Wet
Dry
Wet
SFHL SEHL SLHL SSHL
Std. High Low High All kW Low High Low High
90
27000 0.40 0.53 0.60 0.80 - 0.25 0.13 0.26 0.31 0.22 0.32 0.11 0.13 - 0.68 0.65 - 0.2
32000 0.53 0.70 0.80 1.03 - 0.31 0.16 0.35 0.41 0.3 0.43 0.14 0.16 - 0.84 0.84 - 0.31
37000 0.67 0.88 1.01 1.32 - 0.39 0.23 0.45 0.52 0.4 0.55 0.17 0.19 - 1.02 1.04 - 0.41
42000 0.83 1.08 1.25 1.62 - 0.46 0.29 0.56 0.65 0.5 0.68 0.21 0.22 - 1.19 1.06 - 0.52
45000 0.93 1.20 1.40 1.80 - 0.52 0.32 0.63 0.73 0.58 0.76 0.24 0.24 - - - - 0.63
105
31000 - - 0.63 0.83 - 0.28 0.17 0.33 0.39 0.29 0.4 - 0.13 - 0.82 0.8 - 0.22
35000 - - 0.77 1.01 - 0.36 0.21 0.41 0.48 0.36 0.5 - 0.16 - 0.96 0.96 - 0.32
39000 - - 0.92 1.20 - 0.42 0.26 0.49 0.57 0.44 0.6 - 0.19 - 1.09 1.12 - 0.44
43000 - - 1.08 1.40 - 0.45 0.3 0.57 0.66 0.53 0.71 - 0.22 - 1.22 1.3 - 0.54
46000 1.21 1.56 - 0.55 0.34 0.65 0.75 0.61 0.79 - 0.24 - - - 0.64
115/
130
31000 0.76 1.00 - - - 0.28 0.17 0.33 0.39 0.29 0.4 - 0.13 - 0.82 0.8 - 0.22
35000 0.92 1.21 - - - 0.36 0.21 0.41 0.48 0.36 0.5 - 0.16 - 0.96 0.96 - 0.32
39000 1.10 1.44 - - - 0.42 0.26 0.49 0.57 0.44 0.6 - 0.19 - 1.09 1.12 - 0.44
43000 1.30 1.68 - - - 0.45 0.3 0.57 0.66 0.53 0.71 - 0.22 - 1.22 1.3 - 0.54
46000 1.45 1.86 - - - 0.55 0.34 0.65 0.75 0.61 0.79 - 0.24 - - - - 0.64
Notes:
1. Static pressure drops of accessory components must be added to external static pressure to enter fan selection tables.
2. Gas heat section maximum temperature rise of 60 F.
3. Throwaway filter option limited to 300 ft/min face velocity.
4. Bag filter option limited to 740 ft/min face velocity.
5. Horizontal roof curbs assume 0.50" static pressure drop or double the standard roof curb pressure drop, whichever is greater.
6. No additional pressure loss for model SXHF.
