Installation
Table 12. Air-cooled condenser - approximate operating weights (Lbs./Kg)
Unit
Without Exhaust Fan With Exhaust Fan
SA SX SE SF SL/SS SA SX SE SF SL/SS
20
Lb 4092 4422 4712 4422 4312 4390 4720 5010 4720 4610
Kg 1856 2006 2137 2006 1956 1991 2141 2272 2141 2091
25
Lb 4181 4521 4791 4521 4391 4485 4825 5095 4825 4695
Kg 1896 2050 2173 2050 1992 2034 2188 2311 2188 2129
30
Lb 4572 4932 5202 4932 4812 5029 5389 5659 5389 5269
Kg 2074 2237 2359 2237 2183 2281 2444 2567 2444 2390
40
Lb 6433 6737 7217 6737 6577 7103 7407 7887 7407 7247
Kg 2918 3056 3273 3056 2983 3222 3360 3577 3360 3287
50
Lb 7175 7725 8185 7725 7555 7894 8444 8904 8444 8274
Kg 3255 3504 3713 3504 3427 3581 3830 4039 3830 3753
55
Lb 7425 7975 8455 7975 7815 8144 8694 9174 8694 8534
Kg 3368 3617 3835 3617 3545 3694 3944 4161 3944 3871
60
Lb 8338 8658 9118 8658 8498 9282 9602 10062 9602 9442
Kg 3782 3927 4136 3927 3855 4210 4355 4564 4355 4283
70
Lb 8604 8666 9146 8666 8516 9547 9609 10089 9609 9459
Kg 3903 3931 4148 3931 3863 4330 4358 4576 4358 4290
75
Lb 8843 9173 9653 9173 9023 9786 10116 10596 10116 9966
Kg 4011 4161 4379 4161 4093 4439 4589 4806 4589 4521
90
Lb. N/A 13100 13250 13890 13370 N/A 14440 14590 15230 14710
Kg N/A 5955 6023 6314 6077 N/A 6564 6632 6923 6686
105
Lb. N/A 13710 13860 14500 13980 N/A 15050 15200 15840 15320
Kg N/A 6232 6300 6591 6355 N/A 6841 6909 7200 6964
115
Lb. N/A 13900 14080 14740 14100 N/A 15240 15420 16080 15440
Kg N/A 6318 6400 6700 6409 N/A 6927 7009 7309 7018
130
Lb. N/A 14350 14510 15150 14540 N/A 15690 15850 16490 15880
Kg N/A 6523 6595 6886 6609 N/A 7132 7205 7495 7218
Notes:
1. Weights shown for air-cooled units include the following features: standard coils, 100% economizer, throwaway filters, maximum motor sizes, 460V
XL, high heat.
2. Weights shown represent approximate operating weights and have a ±5% accuracy. To calculate weight for a specific unit configuration, utilize
TOPSS™ or contact the local Trane sales representative. ACTUAL WEIGHTS ARE STAMPED ON THE UNIT NAMEPLATE.
