Installation
Table 21. Compressor electrical service sizing data (20 - 130 ton)
(a)
(a)Evaporative Condenser Units only available in 460V
200V 230V 460V 575V
Tonnage (AC/EC)
No. of
Compressors RLA LRA RLA LRA RLA LRA RLA LRA
20 (Std) 2 41.4 267 35.5 267 18.6 142 15.8 103
20/24 (Hi) 2 41.4 267 35.5 267 18.6 142 15.8 103
25 (Std)
1 41.4 267 35.5 267 18.6 142 15.8 103
1 47 304 42.3 304 20.2 147 17.1 122
25/29 (Hi)
1 41.4 267 35.5 267 18.6 142 15.8 103
1 51.9 315 47 315 22.2 158 19.2 136
30 (Std) 2 51.9 315 47 315 22.2 158 19.2 136
30/36 (Hi)
1 51.9 315 47 315 22.2 158 19.2 136
1 56.9 351 48.8 351 25.5 197 23.1 135
40 (Std)
2 31.3 203 30.4 203 13.1 98 11.9 84
2 37.3 267 31.8 267 15.9 142 14.5 103
40/48 (Hi) 4 37.3 267 31.8 267 15.9 142 14.5 103
50 (Std) 4 41.4 267 35.5 267 18.6 142 15.8 103
50(Hi)
2 41.4 267 35.5 267 18.6 142 15.8 103
2 47 304 42.3 304 20.2 147 17.1 122
55 (Std)/59 (Hi) 4 47 304 42.3 304 20.2 147 17.1 122
60 (Std)
2 47 304 42.3 304 20.2 147 17.1 122
2 51.9 315 47 315 22.2 158 19.2 136
60/73 (Hi) 4 51.9 315 47 315 22.2 158 19.2 136
70/80(Std) 4 56.9 351 48.8 351 25.5 197 23.1 146
75 (Std)
2 60.5 320 52 320 25.4 160 20.3 135
2 83.9 485 74.5 485 37.2 215 29.8 175
75/89 (Hi)
2 60.5 320 52 320 25.4 160 20.3 135
2 83.9 485 74.5 485 37.2 215 29.8 175
90 (Std & High) 4 N/A N/A N/A N/A 36 215 29 175
105 (Hi)
2 N/A N/A N/A N/A 36 215 29 175
2 N/A N/A N/A N/A 45 260 36 210
115 (Std)
2 N/A N/A N/A N/A 36 215 29 175
2 N/A N/A N/A N/A 45 260 36 210
130 (Std) 4 N/A N/A N/A N/A 45 260 36 210
