Trane IntelliPak SAHL Series User Manual

RT-SVX36G-EN 73
Installation
Table 23. Electrical service sizing data —electric heat module (electric heat units only) —
20-130 tons
Voltage
200
FLA
230
FLA
460
FLA
575
FLAModule kW
30 83.3 72.2 36.1 28.9
50 138.8 120.3 60.1 48.1
70 194.3 168.4 84.2 67.4
90 249.8 216.5 108.3 86.6
110 305.3 264.6 132.3 105.9
130 156.4 125.1
150 180.4 144.3
170 204.5 163.6
190 228.5 182.8
Note: Electric heat FLA are determined at 208, 240, 480 and 600 volts.
Table 24. Electrical service sizing data evaporative condenser - All tonnages (24-89T)
Condenser Fan Sump Pump Sump Heater
Qty HP FLA Qty HP FLA kW FLA
15.45.910.51.5533.8
Table 25. Electrical service sizing data — control power transformer
heating and cooling modes — 20-130 tons
Nominal Tons
(Air-cooled/
Evaporative
condensing)
Digit 2
Unit
Function
Voltage
200 230 460 575
20,25,30/24,29,36 A,E,L,S,X 1 1 1 1
20,25,30/24,29,36 F 4 3 2 1
40,50,55,60/48,59,73 A,E,L,S,X 3 2 1 1
40,50,55,60/48,59,73 F 5 4 2 2
70,75/80,89 A,E,L,S,X 5 4 2 2
70,75/80,89 F 8 7 3 3
90,105,115,130 E,L,S,X 5 4 2 2
90,105,115,130 F 8 7 3 3
Table 26. Electrical service sizing data — crankcase heaters
(heating mode on 460/575 volt only) — 20-130 tons
Nominal Tons
(Air-cooled/
Evaporative condensing) (Add) FLA
20-30/24-36 1
40-60/48-73 2
70-75/80-89 3
90-105 3
115-130 4
