Trane MCC Series - System Appearance

MCC-SVU01A 5
Connecting Wire between Indoor Unit & Outdoor Unit
Outdoor Unit
Air Outlet
Air Inlet
Indoor Unit
Front Panel
Air Outlet
Return Air
Drain Pipe
Remote Control Holder
Display Lights
Air Filter (Inside)
Remote Control
Refrigerant Tube
Drain Pipe
High Pressure
Copper Tube
Low Pressure
Copper Tube
Wire
Low Pressure Piping Tape
High Pressure Piping Tape
System Appearance
