Trane MCC Series User Manual

MCC-SVN01A 5
System Appearance
Note : Please refer the owner manual MCC-SVU01A after installation
Air Inlet
Connection Wire
between Indoor Unit & Outdoor Unit
Remote Control Holder
Remote Control
Air Filter (Inside)
Display Lights
Front Panel
Air Outlet
Air Outlet
Return Air
Drain Pipe
High Pressure
Copper Tube
Low Pressure
Copper Tube
Water Pump (Built-in)
Indoor Unit
Air Outlet
Outdoor Unit
(The appearance may vary depending on models)
Drain Pipe
Refrigerant Tube
Refrigerant Flow Control
- R410A : Must install cap. tube at the outside of unit (In the accessory bag)
- R32 : Already built-in the outdoor unit
