ACC-SVN240A-EN 5
General Information
Notes:
• An options board (FIAOPTN002*) must be installed in the unit for the this accessory to operate.
• Supply air sensing tube is standard on SZVAV, MZVAV, and economizer units.
This discharge air sensing kit is designed to sense the supply air temperature downstream of the
fan and/or heat exchanger.
Inspection
1. Unpack all components of the kit.
2. Check carefully for shipping damage. If any damage is found, report it immediately, and file a
claim against the transportation company.
3. Visually inspect the components for shipping damage as soon as possible after delivery, before
it is stored. Concealed damage must be reported within 15 days.
4. If concealed damage is discovered, stop unpacking the shipment.
5. Do not remove damaged material from the receiving location. Take photos of the damage, if
possible. The owner must provide reasonable evidence that the damage did not occur after
delivery.
6. Notify the carrier’s terminal of damage immediately by phone and by mail. Request an
immediate joint inspection of the damage by the carrier and the consignee.
Note: Do not attempt to repair any damaged parts until the parts are inspected by the carrier’s
representative.
Parts List
FIADAST003* T/W Models (digit 39 = B)
FIADAST004* Y/D Models (digit 39 = B)
Quantity Description
1 Temperature sensing module
7Sensing tubes
3 Mounting brackets
1 Pipe insulation
16 Screws
Quantity Description
1 Temperature sensing module
5Sensing tubes
4 Mounting brackets
1 Pipe insulation
16 Screws
To Next Page
