56
RT-SVX070B-EN
Figure 55. Piping diagram – 6 to 12.5 tons standard efficiency – hot gas reheat (TSJ072–150)
SOLENOID
VALVE
BLEED TUBE
MTW-7S VALVE
A
B
INDOOR COIL
AIR
SERVICE
VALVE
NOITCUS
LINE
LIQUID LINE
FILTER DRIER
TXV
TXV BULB
EQUALIZING LINE
SERVICE
VALVE
AIR
OUTDOOR COIL
LOW
PRESSURE
CONTROL
COMPRESSOR
1A
S
D
COMPRESSOR
1B
DISCHARGE
LINE
THERMOSTAT
FROSTAT
HIGH
PRESSURE
CONTROL
D
DISCHARGE
LINE
THERMOSTAT
HIGH
PRESSURE
CONTROL
S
REHEAT
COIL
DISCHARGE LINE
THERMISTOR
CHECK
VALVE
Piping Diagrams
