28 RLC-SVD03A-EN
Current Transformer
Table 5 Compressor Overload DIP Switch Settings
Compressor
To n s Volt s/Hz RLA
Primary Turns
Through Current
Transformer
Current
Transformer
Extension
*
Overload Setting
Dip Sw/Decimal
12345
**
35 200/60 115 1 -02 01011/11
230/60 100 1 -01 11111 /3 1
346/50 58 1 -10 01100/12
380/60 61 1 -10 10000/16
400/50 50 1 -10 00000/0
460/60 50 1 -10 00000/0
575/60 40 1 -01 01111/15
40 200/60 142 1 -02 11011/27
230/60 124 1 -02 10001/17
346/50 72 1 -01 00111/7
380/60 75 1 -01 01010/10
400/50 62 1 -10 10001/17
460/60 62 1 -10 10001/17
575/60 50 1 -01 11111 / 3 1
50 200/60 192 1 -03 11100/28
230/60 167 1 -03 10010/18
346/50 96 1 -01 11100/28
380/60 101 1 -02 00001/1
400/50 84 1 -01 10011/19
460/60 84 1 -01 10011/19
575/60 67 1 -02 10111/23
60 200/60 233 1 -04 10011/19
230/60 203 1 -04 01000/8
346/50 117 1 -02 01101/13
380/60 123 1 -02 10001/17
400/50 101 1 -02 00001/1
460/60 101 1 -02 00001/1
575/60 81 1 -03 10000/16
*The current transformer base part number is X13580253. The numbers in this column are suffixes of the base part number.
**On the DIP switch, 1=ON, O=OFF. The decimal value should be set in the compressor overload setting menu of the UCM. If the
DIP switch value does not match the decimal value entered into the UCM, the related compressor(s) will continue to run, but a
diagnostic will be initiated, both settings will be ignored, and the UCM will use the lowest possible trip setting value.
