RLC-SVD03A-EN 43
Module Power and Miscellaneous I/O
Select Report Group
This group of four keys allows the operator to select and view the following
reports:
- Custom Report
- Chiller Report
- Refrigerant Report
- Compressor Report
The Custom Report is the only report of the four that is defined by the
operator. Any display under the other three reports can be added to the
Custom Report by pressing the plus key while the desired read-out is on
the display. A maximum of 20 entries can be contained under the Custom
Report. Items can be deleted from the Custom Report by pressing the minus
key when the desired read-out is on the display. The operator must be in
the Custom Report menu to delete the desired item.
The Chiller Report, Refrigerant Report and Compressor Report are informa-
tional reports that give current status. Each report and its contents are
discussed in detail on the following pages.
Figure 8 Operator Interface Adaptive Control
