Trane R Series Diagnostic Troubleshooting Repair

60 RLC-SVD03A-EN
Module Power and Miscellaneous I/O
Electronic Expansion Valve Location
The valve should be installed with the motor in a vertical position, or no
greater than 45° from vertical, as shown in Figure 16. This will prevent oil
logging and the possibility of contamination reaching the motor cavity. The
valve should also be installed as close to the evaporator as possible.
Figure 15 SHEI Valve
5DLQWLJKW)OH[&RQQHFWRU
0RWRU&DS
)ORZ
9DOYH%RG\
3XVK5RG
'ULYH$VVHPEO\
([WHQGHG&RSSHU)LWWLQJV
0RWRU

Trane R Series Specifications

General

Brand	Trane
Model	R Series
Category	Chiller
Language	English
