System Appearance
1 Front panel
2 Filter
3 Electrostatic filter (white -green
color)
4 LTC filter (green color)
5 Manual operation switch
6 Air defletion louver - horizontal
7 Wiring access panel
8 Screw cover
9 Air deflection louver - vertical
10 Operation indication lamps
11 Power supply cables
12 Connection tubes
13 Drain hose
14 Front grill
15 Wireless remote control
6
MCW-SVU03A-E4
Return air lnlet
Supply air outlet
Return air inlet
Air discharge
Indoor unit
Outdoor Unit
*:item 3 and item 4 not available for
MCW /MWW526.
1
2
2
4
15
14
13
3
6
8
10
12
5
7
11
9
