Trane S8V2C080M5PC User Manual

20
S8V2-SVX001-1A-EN
Table 7. S8V2B080M4P Cooling Airflow (continued)
S8V2B080M4P Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor Tonnage
- "Odt" (tons)
Airflow Setting -
"CPC" (CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
3.0
450
CFM / WATTS 1353 / 230 1348 / 292 1343 / 358 1339 / 426 1335 / 496
420
CFM / WATTS 1266 / 192 1261 / 250 1256 / 312 1252 / 377 1247 / 444
400
CFM / WATTS 1208 / 169 1203 / 225 1198 / 285 1193 / 347 1189 / 412
370
CFM / WATTS 1121 / 138 1115 / 191 1110 / 247 1105 / 306 1101 / 367
350
CFM / WATTS 1062 / 120 1056 / 170 1051 / 224 1046 / 281 1041 / 340
330
CFM / WATTS 1004 / 103 997 / 151 992 / 203 987 / 258 982 / 315
310
CFM / WATTS 945 / 88 938 / 134 932 / 184 927 / 236 922 / 292
290
CFM / WATTS 886 / 75 879 / 119 873 / 166 867 / 216 863 / 270
3.5
450
CFM / WATTS 1568 / 349 1564 / 420 1559 / 494 1556 / 571 1552 / 650
420
CFM / WATTS 1468 / 289 1463 / 356 1459 / 427 1455 / 499 1451 / 574
400
CFM / WATTS 1401 / 253 1396 / 318 1392 / 385 1387 / 455 1383 / 528
370
CFM / WATTS 1300 / 206 1295 / 266 1290 / 330 1286 / 396 1282 / 464
350
CFM / WATTS 1232 / 178 1227 / 235 1222 / 296 1218 / 359 1213 / 425
330
CFM / WATTS 1165 / 153 1159 / 207 1154 / 265 1149 / 326 1145 / 389
310
CFM / WATTS 1096 / 130 1091 / 182 1085 / 237 1080 / 295 1076 / 356
290
CFM / WATTS 1028 / 110 1022 / 159 1016 / 212 1011 / 267 1007 / 325
4.0
(a)
450
CFM / WATTS 1780 / 503 1776 / 584 1773 / 667 1769 / 753 1766 / 841
420
CFM / WATTS 1667 / 416 1663 / 492 1659 / 570 1656 / 651 1652 / 734
400
CFM / WATTS 1592 / 364 1587 / 436 1583 / 512 1579 / 590 1576 / 670
370
CFM / WATTS 1477 / 294 1473 / 362 1469 / 433 1464 / 506 1461 / 581
350
(a)
CFM / WATTS 1401 / 253 1396 / 318 1392 / 385 1387 / 455 1383 / 528
330
CFM / WATTS 1324 / 217 1319 / 278 1314 / 342 1310 / 409 1306 / 478
310
CFM / WATTS 1247 / 184 1242 / 242 1237 / 303 1232 / 367 1228 / 433
290
CFM / WATTS 1169 / 154 1164 / 209 1159 / 267 1154 / 328 1150 / 392
Table 8. S8V2C080M5P Heating Airflow
S8V2C080M5P Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 41,800
2nd Stage Capacity = 64,800
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 748
CFM 771 741 711 682 652
Temp. Rise
50 52 54 56 58
Watts 46 90 134 178 221
Medium Low
(a)
878
CFM 879 854 830 805 781
Temp. Rise
44 45 46 47 48
Watts 59 116 174 232 290
Medium 943
CFM 958 948 938 929 919
Temp. Rise
40 41 41 42 42
Watts 70 132 194 256 318
High
1073
CFM 1035 1026 1016 1007 997
Temp. Rise
37 38 38 39 40
Watts 90 150 210 271 331
Heating 2nd
Stage
Low 1150
CFM 1175 1159 1142 1126 1109
Temp. Rise
50 51 52 53 53
Watts 105 174 243 312 381
Medium Low
(a)
1350
CFM 1387 1373 1359 1345 1331
Temp. Rise
43 43 43 44 44
Watts 154 243 333 422 512
Medium 1450
CFM 1446 1444 1443 1441 1439
Temp. Rise
41 41 41 41 41
Watts 94 215 336 457 577
High
1650
CFM 1642 1621 1601 1580 1560
Temp. Rise
36 36 37 37 38
Watts 279 373 467 561 655
AAiirrffllooww TTaabblleess
