Horizontal flow Energy Recovery Wheel (ERW - H)
50 Pa 150 Pa 250 Pa 350 Pa
Unit size
«Airflow
m3/h»
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
290-340
1080 n/a n/a n/a n/a n/a n/a 0.3 kW 692 24 Hz 0.5 kW 835 28 Hz
2450 n/a n/a n/a n/a n/a n/a 0.3 kW 764 26 Hz 0.5 kW 886 30 Hz
3820 n/a n/a n/a 0.4 kW 682 23 Hz 0.4 kW 842 29 Hz 0.7 kW 946 32 Hz
5190 0.4 kW 628 21 Hz 0.4 kW 797 27 Hz 0.6 kW 926 32 Hz 0.9 kW 1017 35 Hz
6560 0.5 kW 778 27 Hz 0.6 kW 909 31 Hz 0.8 kW 1015 35 Hz 1.1 kW 1096 37 Hz
7930 0.6 kW 921 31 Hz 0.8 kW 1022 35 Hz 1.1 kW 1111 38 Hz 1.4 kW 1187 40 Hz
9300 0.9 kW 1059 36 Hz 1.2 kW 1137 39 Hz 1.5 kW 1213 41 Hz 1.8 kW 1287 44 Hz
10670 1.3 kW 1194 41 Hz 1.6 kW 1256 43 Hz 2.0 kW 1323 45 Hz 2.3 kW 1396 48 Hz
12040 1.7 kW 1329 45 Hz 2.1 kW 1379 47 Hz 2.5 kW 1441 49 Hz 2.9 kW 1514 52 Hz
13410 2.3 kW 1466 50 Hz 2.7 kW 1508 51 Hz 3.1 kW 1565 53 Hz 3.5 kW 1637 56 Hz
14780 2.9 kW 1607 55 Hz 3.4 kW 1643 56 Hz 3.9 kW 1695 58 Hz 4.3 kW 1764 60 Hz
16150 3.7 kW 1753 60 Hz 4.2 kW 1783 61 Hz 4.7 kW 1829 62 Hz 5.1 kW 1891 65 Hz
17520 4.5 kW 1905 65 Hz 5.1 kW 1927 66 Hz 5.7 kW 1963 67 Hz 6.2 kW 2012 69 Hz
18890 5.4 kW 2061 70 Hz 6.1 kW 2072 71 Hz 6.7 kW 2092 71 Hz n/a n/a n/a
20260 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
21600 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
Horizontal flow Energy Recovery Wheel (ERW - H)
50 Pa 150 Pa 250 Pa 350 Pa
Unit size
«Airflow
m3/h»
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
275-300-
350
1020 n/a n/a n/a n/a n/a n/a 0.3 kW 687 23 Hz 0.6 kW 823 28 Hz
2310 n/a n/a n/a n/a n/a n/a 0.3 kW 757 26 Hz 0.6 kW 872 30 Hz
3600 n/a n/a n/a 0.4 kW 668 23 Hz 0.4 kW 831 28 Hz 0.7 kW 931 32 Hz
4890 0.4 kW 595 20 Hz 0.4 kW 777 27 Hz 0.5 kW 911 31 Hz 0.8 kW 998 34 Hz
6180 0.5 kW 738 25 Hz 0.5 kW 883 30 Hz 0.7 kW 995 34 Hz 1.1 kW 1072 37 Hz
7470 0.6 kW 877 30 Hz 0.8 kW 991 34 Hz 1.0 kW 1085 37 Hz 1.4 kW 1157 39 Hz
8760 0.8 kW 1009 34 Hz 1.1 kW 1100 38 Hz 1.4 kW 1180 40 Hz 1.7 kW 1250 43 Hz
10050 1.1 kW 1138 39 Hz 1.4 kW 1211 41 Hz 1.8 kW 1282 44 Hz 2.1 kW 1351 46 Hz
11340 1.5 kW 1266 43 Hz 1.9 kW 1325 45 Hz 2.3 kW 1390 47 Hz 2.6 kW 1461 50 Hz
12630 2.0 kW 1394 48 Hz 2.4 kW 1444 49 Hz 2.8 kW 1505 51 Hz 3.2 kW 1576 54 Hz
13920 2.6 kW 1525 52 Hz 3.0 kW 1568 53 Hz 3.5 kW 1625 55 Hz 3.8 kW 1696 58 Hz
15210 3.2 kW 1659 57 Hz 3.7 kW 1696 58 Hz 4.2 kW 1749 60 Hz 4.6 kW 1818 62 Hz
16500 4.0 kW 1796 61 Hz 4.5 kW 1827 62 Hz 5.0 kW 1874 64 Hz 5.5 kW 1937 66 Hz
17790 4.8 kW 1937 66 Hz 5.4 kW 1960 67 Hz 6.0 kW 1997 68 Hz 6.5 kW 2048 70 Hz
19080 5.8 kW 2080 71 Hz 6.4 kW 2092 71 Hz n/a n/a n/a n/a n/a n/a
20400 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
Horizontal flow Energy Recovery Wheel (ERW - H)
50 Pa 150 Pa 250 Pa 350 Pa
Unit size
«Airflow
m3/h»
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
400-500-
600
1620 n/a n/a n/a 0.3 kW 423 14 Hz 0.4 kW 562 19 Hz 0.8 kW 656 22 Hz
3680 n/a n/a n/a 0.3 kW 482 16 Hz 0.5 kW 607 21 Hz 0.9 kW 694 24 Hz
5740 0.5 kW 407 14 Hz 0.4 kW 549 19 Hz 0.6 kW 660 22 Hz 1.1 kW 740 25 Hz
7800 0.5 kW 500 17 Hz 0.6 kW 622 21 Hz 0.9 kW 720 24 Hz 1.3 kW 794 27 Hz
9860 0.7 kW 595 20 Hz 0.9 kW 700 24 Hz 1.2 kW 786 27 Hz 1.7 kW 854 29 Hz
11920 1.0 kW 694 24 Hz 1.3 kW 783 27 Hz 1.7 kW 859 29 Hz 2.2 kW 922 31 Hz
13980 1.4 kW 796 27 Hz 1.7 kW 870 29 Hz 2.2 kW 937 32 Hz 2.7 kW 996 34 Hz
16040 1.8 kW 900 31 Hz 2.3 kW 961 33 Hz 2.8 kW 1019 35 Hz 3.4 kW 1075 36 Hz
18100 2.5 kW 1007 34 Hz 3.0 kW 1056 36 Hz 3.6 kW 1107 38 Hz 4.2 kW 1159 39 Hz
20160 3.2 kW 1115 38 Hz 3.9 kW 1154 39 Hz 4.5 kW 1198 41 Hz 5.1 kW 1247 42 Hz
22220 4.1 kW 1226 42 Hz 4.8 kW 1255 43 Hz 5.6 kW 1293 44 Hz 6.2 kW 1339 45 Hz
24280 5.1 kW 1339 45 Hz 6.0 kW 1359 46 Hz 6.7 kW 1390 47 Hz 7.5 kW 1434 49 Hz
26340 6.2 kW 1452 49 Hz 7.2 kW 1464 50 Hz 8.1 kW 1489 50 Hz 8.9 kW 1529 52 Hz
28400 7.6 kW 1567 53 Hz 8.7 kW 1570 53 Hz 9.6 kW 1589 54 Hz 10.5 kW 1625 55 Hz
30460 9.1 kW 1681 57 Hz 10.3 kW 1675 57 Hz 11.4 kW 1688 57 Hz 12.3 kW 1718 58 Hz
32450 10.7 kW 1791 61 Hz 12.1 kW 1776 60 Hz 13.3 kW 1781 60 Hz n/a n/a n/a
