Trane TTK 536 KB User Manual

15TTK-SVN001-EN
Models
50Hz 60Hz
TTK 048 KD TTK 048 K4
TTK 060 KD TTK 060 K4
GL1 L2 L3LL1 LL2
BLK RD YL
MS-3
FAN
MTR1
WH
CF2
CF1
BR
BR
S
RC
FAN
MTR2
BLK
BLK
WH
S
RC
MS-1 MS-2
BLK YL
CPR
2
13
FROM INDOOR UNIT
220-240V/1pH/50Hz
200-240V/1pH/60Hz
BL BLK
LPCO HPCO
C1 C2MS
CPR COMPRESSOR
CF1, 2 FAN CAPACITOR
FAN MTR1, 2 FAN MOTOR
HPCO HIGH PRESSURE CUT-OUT
LPCO LOW PRESSURE CUT-OUT
MS COMPRESSOR MOTOR CONTACTOR
 TERMINAL
 JUNCTION
 IDENTIFIED TERMINAL
 COIL
 TERMINAL BOARD BY OTHERS
 TERMINAL BOARD BY FACTORY
 FIELD WIRING
 FACTORY WIRING
 RELAY CONTACT N.O.
 CAPACITOR
 PRESSURE SENSING SWITCH
LEGEND
1.POWER WIRING AND GROUNDING OF
 EQUIPMENT MUST COMPLY WITH
 LOCAL CODES.
2.USE COPPER CONDUCTORS ONLY.
3.THREE PHASE CONDENSING UNITS
 REQUIRE TWO POWER SUPPLY
 SOURCES AS SHOWN.
NOTES:
BL BLUE
BLK BLACK
BR BROWN
GR GRAY
OR ORANGE 
RD RED
WH WHITE
YL YELLOW
COLOR CODE
380-415/3/50
460/3/60
220-240/1/50
200-240/1/60
Layout 14/1/03, 10:16 AM15
Black
