Trane TurboTorch - Swirl Propane and Mapp Tips; Components

RSP-PRC023-EN10
Propane and Mapp
®
TIP00135
T-2 (0386-0150)
TIP00136
T-3 (0386-0151)
TIP00133
T-4 (0386-0152)
TIP00134
T-5 (0386-0153)
TIP00137
T-6 (0386-0154)
TurboTorch Tips
Copper Tubing Size Capacity Copper Tubing Size Capacity
Tip Size Gas Flow Propane Gas Mapp
®
Gas Replacement
ServiceFirst @24 PSI @36 PSI Soft Solder Silver Braze Soft Solder Silver Braze Orifice
Item No. Mfg. No. in. mm lb/hr lb/hr in. mm in. mm in. mm in. mm Model
TIP00135 T-2
5
/16 8.0 .14 .17
1
/8–
1
/4 3–10
1
/16–
1
/4 1–6
1
/8–
1
/2 3–12
1
/8–
1
/4 3–10 OR-A2
TIP00136 T-3
7
/16 11.1 .20 .25
1
/4–1 6–25
1
/8–
1
/2 3–10
1
/4–1
1
/2 10–40
1
/4–
1
/2 6–15 OR-T3
TIP00133 T-4
1
/2 12.7 .39 .48
1
/4–1
1
/2 10–40
1
/4–
3
/4 6–15
1
/4–2
1
/2 10–60
1
/4–1
1
/4 6–35 OR-A3
TIP00134 T-5
3
/4 19.0 1.10 1.3 1
1
/2–2
1
/2 25–60
1
/2–1
1
/4 15–35 1–4 25–100
1
/2–2 15–50 OR-A8
TIP00137 T-6 1 25.4 2.10 2.5 1
1
/2–4 40–100
3
/4–2 20–50 1
1
/2–6 25–150
3
/4–4 20–100 OR-T6
Swirl Propane and Mapp
®
Tips / Components
