11RSP-PRC023-EN
Propane and Mapp
®
Pro-Line Tips
Air Air Copper Tubing Size Capacity Copper Tubing Size Capacity
Tip Size Propane MAPP
®
Propane Gas MAPP
®
GAS Replacement
ServiceFirst @24 PSI @42 PSI Soft Solder Silver Braze Soft Solder Silver Braze Orifice Tip
Item No. Mfg. No. in. mm lb/hr lb/hr in. mm in. mm in. mm in. mm Model Ends
TIP00139 PL-4T
7
/16 11.1 .52 .69
1
/4–1
1
/2 10–40
1
/4
3
/4 6–15
1
/4–2
1
/2 10–60
1
/4–1
1
/4 6–35 OR-PL4T 4T-TE
Soldering and brazing sizes based on propane. Capacity larger on MAPP
®
GAS.
TIP00139
PL-4T (0386-0822)
HDL00916
H-4 Handle
(0386-0300)
Ergonomically designed handle with
valve rear and quick disconnect. Fits all
Proline and TurboTorch tips. “B” size
9/16 in.-18 hose connections.
REG00439
R-LP Regulator
(0386-0705)
Brass regulator for use with MAPP
®
,
Propane, and other LPG fuel gas.
Adjustable to 60 psi. Fits standard POL
valve and 9/16 in.-18 LH hose nut. Not
for use with Acetylene. R-LP-993
Regulator for British 993 markets,
Part No. 0386-0328
Swirl Propane and Mapp
®
Tips / Components
