Trane TurboTorch - Page 7

7RSP-PRC023-EN
Air Acetylene
Swirl Air Acetylene Tips
TIP00147
PL-3A (0386-0874)
TIP00148
PL-5A (0386-0818)
TIP00149
PL-8A (0386-0819)
TIP00150
PL-12A (0386-0820)
Tip Size Gas Flow Copper Tubing Size Capacity Replacement Replacement
ServiceFirst @14 PSI (0.9 BAR) Soft Solder Silver Braze Orifice Tip
Item No. Mfg. No. in. mm SCFH m
3
/Hr in. mm in. mm Model Ends
TIP00147 PL-3A
1
/4 5.0 3.6 .31
1
/4–1 10–25
1
/8–
1
/2 3–12 OR-A3 3A-TE
TIP00148 PL-5A
3
/16 6.4 5 .42
3
/4–1
1
/2 20–40
1
/4–
3
/4 10–20 OR-A8 5A-TE
TIP00149 PL-8A
5
/16 7.9 7 .59 1–2 25–50
1
/2–1 15–30 ORPL-8A 8A-TE
TIP00150 PL-12A
3
/8 9.5 9 .76 2–4 50–90 1–2 25–50 OR-T-6 12A-TE
Note: For air conditioning, add 1/8 in. for type “L” tubing
