RSP-PRC023-EN6
Air Acetylene
Swirl Air Acetylene Tips
TIP00131
A-2 (0386-0100)
TIP00142
A-3 (0386-0101)
TIP00143
A-5 (0386-0102)
TIP00144
A-8 (0386-0103)
TIP00145
A-11 (0386-0104)
TIP00146
A-14 (0386-0105)
TIP00132
A-32 (0386-0106)
Tip Size Gas Flow Copper Tubing Size Capacity Replacement
ServiceFirst @14 PSI (0.9 BAR) Soft Solder Silver Braze Orifice
Item No. Mfg. No. In. mm Ft
3
/Hr M
3
/Hr In. mm In. mm Model
TIP00131 A-2
1
/8 4.8 2.0 .17
1
/8
1
/2 3–15
1
/8
1
/4 3–10 OR-A2
TIP00142 A-3
3
/16 6.4 3.6 .31
1
/4–1 10–25
1
/8
1
/2 3–12 OR-A3
TIP00143 A-5
1
/4 7.9 5.7 .48
3
/4–1
1
/2 20–40
1
/4
3
/4 10–20 OR-A5
TIP00144 A-8
5
/16 9.5 8.3 .71 1–2 25–50
1
/2–1 15–25 OR-A8
TIP00145 A-11
7
/16 11.1 11.0 .94 1
1
/2–3 40–75
7
/8–1
5
/8 20–40 OR-A11
TIP00146 A-14
1
/2 12.7 14.5 1.23 2–3
1
/2 50–90 1–2 30–50 OR-A14
TIP00132 A-32*
3
/4 19.0 33.2 2.82 4–6 100–150 1
1
/2–4 40–100 OR-A32
*Use with large tank only. NOTE: For air conditioning, add 1/8 in. for type “L” tubing.
