23
Performance
Data
SSP-PRC002-EN
(System)
Table PD-12 — Gross Heating Capacities (MBh)
TWA200B Heat Pump with TWE200B Air Handler At 6675 CFM (I-P)
Outdoor Heating Capacity (BTUH/1000) At Total Power in Kilowatts At
Temperature Indicated Indoor Dry Bulb Temperature Indicated Indoor Dry Bulb Temperature
(°F) 60707580 60707580
-18 42.4 79.1 84.7 87.4 11.5 15.4 16.6 17.6
-13 68.2 86.2 90.2 92.3 13.0 15.6 16.7 17.7
-8 81.5 93.8 96.7 98.0 13.6 15.9 16.9 17.9
-3 93.1 101.8 103.7 104.5 14.1 16.2 17.1 18.1
2 104.2 110.2 111.4 111.7 14.5 16.4 17.4 18.3
7 115.2 119.2 119.8 119.7 14.9 16.7 17.6 18.6
12 126.6 128.8 128.9 128.5 15.2 17.0 17.9 18.9
17 138.2 139.1 138.8 138.2 15.5 17.3 18.2 19.2
22 150.3 150.1 149.5 148.6 15.9 17.6 18.6 19.6
27 162.9 161.8 160.9 159.8 16.2 18.0 18.9 20.0
32 176.1 174.3 173.2 171.9 16.5 18.3 19.3 20.4
37 189.2 186.9 185.6 184.3 16.9 18.7 19.7 20.8
42 202.8 200.0 198.6 197.2 17.2 19.1 20.2 21.3
47 216.9 213.8 212.3 210.8 17.6 19.5 20.6 21.8
52 231.9 228.5 226.8 225.3 18.0 20.0 21.1 22.3
57 247.4 243.6 241.9 240.3 18.4 20.5 21.7 22.9
62 263.2 259.1 257.2 255.6 18.9 21.0 22.2 23.5
67 279.3 274.8 272.8 271.0 19.4 21.6 22.8 24.1
72 295.9 291.1 289.0 287.0 20.0 22.2 23.4 24.7
Table PD-12 — Gross Heating Capacities (kW)
TWA200B Heat Pump with TWE200B Air Handler At 11340 m
3
/h (SI)
Outdoor Heating Capacity (kW) At Total Power in Kilowatts At
Temperature Indicated Indoor Dry Bulb Temperature Indicated Indoor Dry Bulb Temperature
(°C) 15.6 21.1 23.9 26.7 15.6 21.1 23.9 26.7
-27.8 12.4 23.2 24.8 25.6 5.5 6.0 6.2 6.5
-25.0 20.0 25.3 26.4 27.0 5.6 6.1 6.3 6.6
-22.2 23.9 27.5 28.3 28.7 5.7 6.2 6.5 6.7
-19.4 27.2 29.8 30.4 30.6 5.8 6.3 6.6 6.9
-16.7 30.5 32.3 32.6 32.7 5.9 6.5 6.7 7.0
-13.9 33.7 34.9 35.1 35.1 6.0 6.6 6.9 7.2
- 11 . 1 3 7. 1 3 7. 7 3 7. 8 3 7. 6 6 . 2 6 . 7 7.0 7.4
-8.3 40.5 40.7 40.7 40.5 6.3 6.9 7.2 7.5
-5.6 44.0 43.9 43.8 43.5 6.5 7.0 7.4 7.7
-2.8 47.7 47.4 47.1 46.8 6.6 7.2 7.5 7.9
0.0 51.6 51.0 50.7 50.3 6.8 7.4 7.7 8.1
2.8 55.4 54.7 54.3 54.0 6.9 7.6 7.9 8.3
5.6 59.4 58.6 58.1 57.7 7.1 7.8 8.1 8.5
8.3 63.5 62.6 62.2 61.7 7.3 8.0 8.4 8.8
11.1 67.9 66.9 66.4 66.0 7.5 8.2 8.6 9.0
13.9 72.4 71.3 70.8 70.3 7.7 8.4 8.8 9.2
16.7 77.1 75.9 75.3 74.8 7.9 8.7 9.1 9.5
19.4 81.8 80.5 79.9 79.4 8.1 8.9 9.3 9.8
22.2 86.6 85.2 84.6 84.0 8.4 9.2 9.6 10.0
Correction Factors - Other Airflows
(Table Value x Correction Factor = Value at new airflow)
Airflow 6000 cfm 7325 cfm
10194 m
3
/h 12445 m
3
/h
Heating Capacity x 0.99 x 1.01
Compressor kW x 1.02 x 0.98
Values at ARI Rating Conditions of:
70F (21.1C) and 47/43F (8.3/6.1C)(High Temp.Cond.)
70F (21.1C) and 17/15F (-8.3/-9.4C)(Low Temp. Cond)
Airflow = 6700 cfm (11383 m
3
/h)
Heating Capacity (High Temp.) = 214,000 (62.66)
Heating Capacity (Low Temp.) = 139,000 (40.70)
Compressor Power (High Temp) = 15.83 kW
Compressor Power (Low Temp) = 13.50 kW
Coeff. Of Perf. (High Temp) = 3.2
Coeff. Of Perf. (Low Temp) = 2.3
Outdoor Fan Power = 1,200 watts
Indoor Fan Power = 2,300 watts
Note:
1. Rated with 25 feet of 1-3/8” suction and 1/2" liquid line."
