47SSP-PRC002-EN
Dimensional
Data
(Air Handlers)
Table DD-1 — Air Handler Dimensions — in. (mm)
Model No. AA AB AC AD AE AF AJ AK AL
TWE050A 35
5
/8 12
1
/16 1
5
/8 32
1
/4 2
15
/16 32
1
/4 7
13
/16 12
3
/8 34
9
/16
(905) (306.4) (41.3) (819.2) (74.6) (819.2) (198.4) (314.3) (878)
TWE075A 45
1
/8 16 1
11
/16 41
15
/16 6
5
/8 41
3
/4 7 16 36
7
/8
(1146.2) (406.4) (42.9) (1065.2) (168.3) (1060.5) (177.8) (406.4) (936.6)
TWE100A 61
1
/8 16 1
11
/16 57
15
/16 6
5
/8 57
13
/16 7 16 36
7
/8
(1552.6) (406.4) (42.9) (1471.6) (168.3) (1468.4) (177.8) (406.4) (936.6)
TWE100B 61
1
/8 16 1
11
/16 57
15
/16 6
5
/8 57
13
/16 7 16 36
7
/8
(1552.6) (406.4) (42.9) (1471.6) (168.3) (1468.4) (177.8) (406.4) (936.6)
Figure DD-9— TWE050A, 075A, 100A and TWE100B Air Handler
All dimensions are in inches and millimeters.
