10 TWE5-PRC001-EN-10-15-99
Performance
Data Cooling English Units
TWJ030CA WITH TWE040CA4-B AT 1100 CFM (CAPACITIES ARE GROSS IN BTUH/1000-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B.W.B.CAP. 7274767880 KW
59 30.7 25.1 27.1 29.1 31.0* 31.6* 2.65
85 63 33.0 21.2 23.2 25.2 27.2 29.2 2.75
67 35.3 16.9 18.9 20.9 22.9 24.9 2.84
71 37.7 12.5 14.5 16.5 18.5 20.4 2.94
59 30.1 24.9 26.9 28.9 30.5* 31.2* 2.78
90 63 32.3 21.0 22.9 24.9 26.9 28.9 2.87
67 34.6 16.6 18.6 20.6 22.6 24.6 2.97
71 37.0 12.2 14.2 16.2 18.2 20.2 3.07
59 29.5 24.6 26.6 28.6 30.0* 30.7* 2.91
95 63 31.7 20.7 22.7 24.7 26.7 28.7 3.00
67 33.9 16.4 18.4 20.4 22.3 24.3 3.10
71 36.2 12.0 14.0 15.9 17.9 19.9 3.20
59 28.8 24.3 26.3 28.3 29.3* 30.0* 3.04
100 63 30.9 20.4 22.4 24.3 26.3 28.3 3.13
67 33.0 16.0 18.0 20.0 22.0 24.0 3.23
71 35.3 11.6 13.6 15.6 17.6 19.6 3.33
59 28.0 24.0 26.0 27.9 28.7* 29.4* 3.17
105 63 30.0 20.0 22.0 24.0 26.0 28.0 3.27
67 32.1 15.7 17.7 19.7 21.7 23.7 3.36
71 34.3 11.3 13.3 15.3 17.3 19.3 3.46
59 26.5 23.3 25.3 26.8* 27.4* 28.1* 3.45
115 63 28.4 19.4 21.4 23.4 25.4 27.3 3.54
67 30.4 15.1 17.1 19.0 21.0 23.0 3.63
71 32.4 10.7 12.7 14.6 16.6 18.6 3.73
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 975 1275
TOTAL CAP. X0.98 X1.02
SENS. CAP. X0.95 X1.07
COMPR. KW X0.99 X1.01
VALUES AT 95/80/67 RATING CONDITIONS
GROSS CAPACITY = 34100 BTUH
AIRFLOW = 1125 CFM
COMPRESSOR POWER = 3104 WATTS
I.D. FAN POWER = 300 WATTS
O.D. FAN POWER = 195 WATTS
E.E.R. = 9.05 BTUH/WATT
NOTE:RATED WITH 25 FEET OF 7/8 SUCT.
AND 3/8 LIQUID LINE
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT. ARE
VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES F.
TWJ036CA WITH TWE030CA4 AT 1100 CFM (CAPACITIES ARE GROSS IN BTUH/1000-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B.W.B.CAP. 7274767880 KW
59 33.9 25.9 27.8 29.7 31.6 33.4 2.52
85 63 36.7 22.4 24.3 26.1 28.0 29.9 2.60
67 39.5 18.4 20.3 22.1 24.0 25.9 2.68
71 42.5 14.3 16.2 18.0 19.9 21.8 2.77
59 33.4 25.7 27.6 29.4 31.3 33.2 2.65
90 63 36.1 22.1 24.0 25.9 27.8 29.6 2.73
67 38.9 18.1 20.0 21.9 23.8 25.6 2.82
71 41.8 14.0 15.9 17.8 19.7 21.5 2.91
59 32.8 25.4 27.3 29.2 31.1 32.9* 2.78
95 63 35.5 21.9 23.8 25.6 27.5 29.4 2.87
67 38.3 17.9 19.8 21.6 23.5 25.4 2.95
71 41.2 13.8 15.7 17.5 19.4 21.3 3.04
59 32.1 25.1 27.0 28.9 30.7 32.4* 2.92
100 63 34.7 21.5 23.4 25.3 27.2 29.0 3.00
67 37.4 17.6 19.4 21.3 23.2 25.1 3.09
71 40.2 13.5 15.3 17.2 19.1 21.0 3.18
59 31.3 24.8 26.7 28.5 30.4 31.8* 3.06
105 63 33.9 21.2 23.1 25.0 26.8 28.7 3.14
67 36.5 17.2 19.1 21.0 22.8 24.7 3.23
71 39.3 13.1 15.0 16.9 18.7 20.6 3.31
59 29.8 24.1 26.0 27.9 29.7 30.6* 3.35
115 63 32.2 20.5 22.4 24.3 26.2 28.0 3.42
67 34.8 16.5 18.4 20.3 22.2 24.0 3.50
71 37.4 12.5 14.3 16.2 18.1 19.9 3.58
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 975 1275
TOTAL CAP. X0.98 X1.02
SENS. CAP. X0.95 X1.06
COMPR. KW X0.99 X1.01
VALUES AT 95/80/67 RATING CONDITIONS
GROSS CAPACITY = 38500 BTUH
AIRFLOW = 1125 CFM
COMPRESSOR POWER = 2957 WATTS
I.D. FAN POWER = 540 WATTS
O.D. FAN POWER = 235 WATTS
E.E.R. = 9.65 BTUH/WATT
NOTE:RATED WITH 25 FEET OF 7/8 SUCT.
AND 3/8 LIQUID LINE
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES F.
TWJ036CA WITH TWE040CA4-B AT 1400 CFM (CAPACITIES ARE GROSS IN BTUH/1000-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B.W.B.CAP. 7274767880 KW
59 37.2 30.6 33.0 35.5 37.6* 38.5* 2.63
85 63 40.1 25.8 28.3 30.7 33.1 35.6 2.71
67 43.1 20.6 23.0 25.4 27.9 30.3 2.80
71 46.2 15.2 17.6 20.1 22.5 25.0 2.89
59 36.5 30.3 32.7 35.2 37.0* 37.9* 2.76
90 63 39.3 25.5 28.0 30.4 32.8 35.3 2.85
67 42.3 20.3 22.7 25.1 27.6 30.0 2.94
71 45.3 14.9 17.3 19.8 22.2 24.7 3.03
59 35.8 30.0 32.4 34.9 36.5* 37.3* 2.90
95 63 38.6 25.2 27.7 30.1 32.5 35.0 2.99
67 41.5 20.0 22.4 24.8 27.3 29.7 3.07
71 44.4 14.6 17.0 19.5 21.9 24.4 3.17
59 34.9 29.6 32.0 34.5 35.7* 36.5* 3.04
100 63 37.6 24.8 27.3 29.7 32.1 34.6 3.13
67 40.4 19.6 22.0 24.4 26.9 29.3 3.22
71 43.3 14.2 16.6 19.1 21.5 24.0 3.31
59 34.0 29.2 31.6 34.1* 34.9* 35.8* 3.19
105 63 36.6 24.4 26.9 29.3 31.7 34.2 3.27
67 39.3 19.2 21.6 24.0 26.5 28.9 3.36
71 42.1 13.8 16.2 18.7 21.1 23.6 3.45
59 32.1 28.4 30.8 32.6* 33.4* 34.2* 3.48
115 63 34.6 23.6 26.1 28.5 30.9 33.4 3.56
67 37.1 18.4 20.8 23.2 25.7 28.1 3.64
71 39.8 13.0 15.4 17.9 20.3 22.8 3.73
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 1175 1525
TOTAL CAP. X0.97 X1.01
SENS. CAP. X0.92 X1.04
COMPR. KW X0.98 X1.01
VALUES AT 95/80/67 RATING CONDITIONS
GROSS CAPACITY = 41300 BTUH
AIRFLOW = 1350 CFM
COMPRESSOR POWER = 3066 WATTS
I.D. FAN POWER = 360 WATTS
O.D. FAN POWER = 235 WATTS
E.E.R. = 10.80 BTUH/WATT
NOTE:RATED WITH 25 FEET OF 7/8 SUCT.
AND 3/8 LIQUID LINE
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES F.
